AUTOMAT HT-102-CLM 2inch Pressure Relief Valve – Spring Loaded Aluminium PRV

Copy Link

Share

Technical Specifications
Show More
Show More
Brand : AUTOMAT (Harit)
Model / SKU : 1-AUTO-03-1-01
Size : 2" (63mm)
End connection : M-THD
Material type : Metal
Colour : Orange
Operation : Auto - Bypass
Operating pressure (range) : 0.5 - 5 Bar

Warranty as Per Brand

100% Original Products

Secure payments

100%Buyer Protection

Top

Brands

10000+ Farmers Trust Us

10000+ Farmers Trust Us

Join Thousands of Satisfied Customers

ISO 9001:2015 Certified

ISO 9001:2015 Certified

International Quality Standards

World Wide Shipping

World Wide Shipping

Fast Delivery to 50+ Countries

24/7 Expert Support

24/7 Expert Support

Always Here to Help You Succeed

In Stock
SKU: 1-AUTO-03-1-01
Price:
Rs. 2,200.00 Save Rs. 1,761.00
Rs. 3,961.00

Inclusive of all taxes
44% Off
Shop Pickup Shop Pickup
Easy EMIShipping & Delivery
Home-Delivery Home-Delivery
CouponReturn/Exchange
Shipping & Delivery Policies

Aqua Irrigation and Agri inputs (AQUA-AGRO) ships its products to almost all parts of India. Orders placed will be shipped within 1 or 2 working days from the ordered date. We ship on all days except Sunday and National Holidays.

For all areas serviced by reputed couriers, the delivery time would be within 1~3  business days of shipping for order weight less than 5 kilogram and 3~10 business days of shipping for order weight more than 5 kilogram (usually classified as bulky or high volume products as per standard shipping policies)

Business days exclude Sundays and other holidays. For other areas the products will be shipped through transport services and may take 1-2 weeks depending on location. At times there might be unexpected delays in the delivery of your order due to unavoidable and undetermined logistics challenges beyond our control for which Aqua Irrigation and Agri inputs (AQUA-AGRO) is not liable and would request its users to cooperate as Aqua Irrigation and Agri inputs (AQUA-AGRO) continuously strives to curb such instances.

Aqua Irrigation and Agri inputs (AQUA-AGRO) reserves the right to cancel your order at its sole discretion in cases where it takes longer than usual delivery time or the shipment is physically untraceable and refund the amount paid for cancelled product(s) to your source account.

Offers and Coupons

Save instantly 2% with online payment
Via UPI, EMI, Credit/Debit Card, Net Banking, Wallets on min. cart value of ₹3000 in Cybernautt Smart WiFi Cameras

Get flat Rs. 100 Off
Min cart value ₹2,000

Click to Copy

Get GST invoice and save up to 18% on business purchases

View
Return-Exchange Policies

RETURN POLICY -

Unfortunately, we do not accept any returns / exchange

But in the following rare and unfortunate scenarios, we will be more than happy to send across a replacement, if the request for replacement has been raised within 7 days of delivery of the order

Wrong products delivered
Missing products in the order
Damaged products delivered
Expired products delivered
Products in any of the above case shall be reported and returned with proper photographic evidence. Product should be returned in unused and  its original packing.

You can raise a request for replacement  by mail on info@aqua-agro.com.  Our customer happiness executives might ask for additional information to analyze and ascertain before processing the request for replacement.

REFUNDS POLICY -

We will notify you once we’ve received and inspected your return, and let you know if the refund was approved or not. If approved, you’ll be automatically refunded within 5-7 working days on your original payment method. Please remember it can take some time for your bank or Credit Card Company to process and post the refund. It might take up to 15 days in some unexpected cases.

Enquiry

You may also like

Recently viewed

  • Description Description
  • Specifications Specifications
  • FAQ FAQ
  • Reviews Customer Ratings

Ensure unmatched safety for your irrigation or water pipeline system with the AUTOMAT HT-102-CLM Pressure Release Valve. This spring-loaded aluminium PRV (Pressure Relief Valve) is engineered to prevent overpressure surges in irrigation networks, pipelines, and pumping systems — safeguarding your investment and reducing maintenance risks.

Made from high-strength cast aluminium with a stainless steel shaft, this valve offers superior corrosion resistance and durability under Indian farming conditions. It is factory-set under real hydraulic conditions with a pressure relief range of 20–80 PSI (1.5–5.5 kg/cm²) and includes an adjustable setting for on-site tuning. When sudden pressure spikes occur — for example, when pumps are switched on or off — this valve automatically opens to release excess pressure to the atmosphere. Once normal conditions return, it closes smoothly, preventing water hammer and pipeline damage.

This 2 inch (63mm) BSP/NPT male-threaded valve comes with an oil-tempered spring for responsive operation, and its orange powder-coated cover provides easy visibility and extra protection in the field. The integrated 1½ inch drain port ensures efficient bypass and safe operation.

Commonly installed before main throttle valves, the AUTOMAT HT-102-CLM is ideal for drip irrigation systems, water line pressure control, and surge prevention — giving farmers and installers peace of mind that their systems stay protected, efficient, and compliant.

AUTOMAT — India’s trusted name for smart water control solutions.

AUTOMAT 2in Spring Loaded Pressure Relief Valve HT-102-CLM FAQs:

1. What does HT-102-CLM pressure release valve protect against?
HT-102-CLM pressure release valve protects pipes and irrigation lines by releasing excess pressure surges.

2. Is the pressure of HT-102-CLM pressure release valve adjustable?
Yes — the pressure of HT-102-CLM pressure release valve can be preset at the factory or adjusted in the field (20–80 PSI).

3. Where should I install HT-102-CLM pressure release valve?
Install HT-102-CLM pressure release valve on the header unit before the main throttle valve for best protection.

4. What is the connection type in a HT-102-CLM pressure release valve?
HT-102-CLM pressure release valve has a 2-inch BSP/NPT male thread and a drain port.

AUTOMAT 2 inch Spring Loaded Pressure Relief Valve HT-102-CLM is used in:

  • Drip and sprinkler irrigation main lines
  • Water pipeline pressure control
  • Surge and water hammer protection
  • Pump line safety for agriculture and landscaping
  • Industrial and commercial water supply systems

More products to complement this purchase:

Technical Specifications
Brand : AUTOMAT (Harit)
Model / SKU : 1-AUTO-03-1-01
Size : 2" (63mm)
End connection : M-THD
Material type : Metal
Colour : Orange
Operation : Auto - Bypass
Operating pressure (range) : 0.5 - 5 Bar
No FAQ available for this product.

No downloads available.

Customers are saying

5.00 ★ (2)
Verified
Description Description

Ensure unmatched safety for your irrigation or water pipeline system with the AUTOMAT HT-102-CLM Pressure Release Valve. This spring-loaded aluminium PRV (Pressure Relief Valve) is engineered to prevent overpressure surges in irrigation networks, pipelines, and pumping systems — safeguarding your investment and reducing maintenance risks.

Made from high-strength cast aluminium with a stainless steel shaft, this valve offers superior corrosion resistance and durability under Indian farming conditions. It is factory-set under real hydraulic conditions with a pressure relief range of 20–80 PSI (1.5–5.5 kg/cm²) and includes an adjustable setting for on-site tuning. When sudden pressure spikes occur — for example, when pumps are switched on or off — this valve automatically opens to release excess pressure to the atmosphere. Once normal conditions return, it closes smoothly, preventing water hammer and pipeline damage.

This 2 inch (63mm) BSP/NPT male-threaded valve comes with an oil-tempered spring for responsive operation, and its orange powder-coated cover provides easy visibility and extra protection in the field. The integrated 1½ inch drain port ensures efficient bypass and safe operation.

Commonly installed before main throttle valves, the AUTOMAT HT-102-CLM is ideal for drip irrigation systems, water line pressure control, and surge prevention — giving farmers and installers peace of mind that their systems stay protected, efficient, and compliant.

AUTOMAT — India’s trusted name for smart water control solutions.

AUTOMAT 2in Spring Loaded Pressure Relief Valve HT-102-CLM FAQs:

1. What does HT-102-CLM pressure release valve protect against?
HT-102-CLM pressure release valve protects pipes and irrigation lines by releasing excess pressure surges.

2. Is the pressure of HT-102-CLM pressure release valve adjustable?
Yes — the pressure of HT-102-CLM pressure release valve can be preset at the factory or adjusted in the field (20–80 PSI).

3. Where should I install HT-102-CLM pressure release valve?
Install HT-102-CLM pressure release valve on the header unit before the main throttle valve for best protection.

4. What is the connection type in a HT-102-CLM pressure release valve?
HT-102-CLM pressure release valve has a 2-inch BSP/NPT male thread and a drain port.

AUTOMAT 2 inch Spring Loaded Pressure Relief Valve HT-102-CLM is used in:

  • Drip and sprinkler irrigation main lines
  • Water pipeline pressure control
  • Surge and water hammer protection
  • Pump line safety for agriculture and landscaping
  • Industrial and commercial water supply systems
